Carbon fiber composite materials, due to their lightweight and high-strength characteristics, are widely used in many high-end fields such as aerospace, automotive manufacturing, and sports equipment. In the manufacturing process of carbon fiber products, the selection and control of the laying angle is one of the key factors determining their performance. Rational laying design not only gives full play to the mechanical advantages of carbon fiber but also effectively improves the structural strength and service life of the product. Therefore, mastering the control method of carbon fiber laying angle is of great significance.



One, Basic Concept of Layup Angle



Carbon fiber composites are usually made up of multi-layer carbon fiber fabrics (prepreg) stacked at a certain angle. The direction of each layer of fiber (i.e., the layup angle) directly affects the material's mechanical properties in different directions. Common layup angles include 0°, 45°, 90°, and -45°, etc. Different combinations of layup angles can achieve directional optimization of properties such as tensile, compressive, and shear.

　　For example, 0° layup mainly enhances the tensile strength of the material along the fiber direction; 90° laying enhances the performance in the vertical direction; while ±45° laying helps to improve the material's shear resistance and impact resistance.



Two, Why Control Layup Angle



The advantage of carbon fiber materials lies in their anisotropic characteristics, that is, their performance varies in different directions. By precisely controlling the layup angle, materials can be customized for stiffness, strength, and toughness according to design requirements, making them more adaptable to specific application environments. For example, in the design of aircraft wings, the layup direction needs to be adjusted according to the distribution of aerodynamic loads to achieve the unity of structural lightweight and high strength.



In addition, incorrect layup angles may lead to uneven stress distribution within the material, reducing overall performance and even causing early failure. Therefore, scientifically and reasonably designing the layup sequence and angle is the key to ensuring the quality of carbon fiber products.



Three, Control Methods of Layup Angle



1. Computer-Aided Design (CAD/CAE)



Modern carbon fiber structural design commonly uses finite element analysis software (such as ANSYS, ABAQUS, etc.) for simulation and analysis, predicting performance under different layup angles by establishing material models and loading conditions, thus optimizing the design scheme.

　　2. Automated Fiber Placement Technology (AFP)



In industrial manufacturing, the use of automated fiber placement machines (AFP, Automated Fiber Placement) can accurately lay carbon fiber prepreg at predetermined angles on the mold surface, significantly improving production efficiency and product consistency.



3. Manual Laying and Quality Control



For small batch or complex-shaped products, manual laying is still required. At this time, it is necessary to strictly follow the process specifications, use angle positioning tools, and strengthen process inspection to ensure that each layer's angle is accurate and error-free.



4. Post-processing and Inspection

　　After laying up and curing, internal defects need to be checked through means such as ultrasonic testing and X-ray to ensure that the overall structural quality meets the design requirements.



Four, Conclusion



In summary, the angle of carbon fiber layup is an important parameter that determines its ultimate performance. Through scientific design and precise control of the layup angle, the optimal configuration of material properties can be achieved to meet diverse engineering requirements. With the continuous advancement of automation technology and simulation analysis methods, the application of carbon fiber in the future will be more extensive, and the control of layup angle will also be more intelligent and refined.



---
