Electrophoretic coating is an advanced technology widely used in the surface treatment of metals, especially playing an important role in industries such as automobiles, household appliances, and building materials. It deposits paint particles on the workpiece surface under the action of an electric field, forming a uniform and dense coating film. Among them, voltage is one of the key parameters affecting the electrophoretic process, directly related to the quality, efficiency, and stability of the coating. Therefore, scientifically and reasonably setting the voltage is the premise of ensuring the excellent effect of electrophoretic coating.



One, Influence of Voltage on Electrocoating



During the electrocoating process, the voltage level directly affects the migration speed and deposition efficiency of the paint particles. Generally speaking, the higher the voltage, the stronger the electric field force acting on the paint particles, the faster the movement speed, the higher the deposition rate, and the thicker the coating. However, excessive voltage can lead to excessive coating thickness, pinholes, bubbles, and even breakdown phenomena; while low voltage can lead to thin and uneven coating, reducing the coating efficiency and protective performance.



In addition, voltage will also affect the stability of the bath liquid. Excessive voltage will intensify the electrolysis of water in the bath liquid, produce a large number of bubbles, which will affect the quality of the coating and may damage the equipment. Therefore, when setting the voltage, various factors need to be considered comprehensively to achieve the best effect.



Two, Basic Principles of Voltage Setting



1. Set according to the type and formula of the paint

　　Different types of electrocoating paints (such as anodic electrocoating paint and cathodic electrocoating paint) have different responses to voltage. Cathodic electrocoating paint usually has higher voltage resistance and the applicable voltage range is generally 150～350V; while anodic electrocoating paint is relatively lower, usually between 80～200V. In addition, the solid content of the paint and the type of additives will also affect the choice of voltage.



2. Consider the shape and area of the workpiece



When the workpiece has a complex shape or deep cavity structure, the voltage should be appropriately reduced to avoid edge effects and uneven coating. For large-area workpieces, the voltage needs to be appropriately increased to ensure uniform coating.



3. Refer to bath liquid parameters

　　Factors such as bath liquid temperature, pH value, and conductivity will also affect the relationship between current and voltage. In actual operation, voltage adjustment should be carried out on the basis of stable bath liquid parameters.

　　4. Combine production efficiency and coating requirements

　　If high efficiency is pursued, the voltage can be appropriately increased to accelerate the deposition speed; if more emphasis is placed on the appearance and corrosion resistance of the coating, then a moderate voltage should be chosen to ensure the dense and uniform coating.



Three, Practical Methods for Voltage Setting



In actual operation, enterprises usually adopt the 'step-up method' to set the voltage: that is, to start the electrocoating process with a lower voltage at the beginning, and then gradually increase to the set value within 1～2 minutes. This method helps to reduce bubbles and coating defects, protect the equipment, and improve the quality of coating.



In addition, it is also necessary to monitor in conjunction with current density. Ideally, the current density should be maintained between 0.2～0.6A/dm². If the current density is too high, it indicates that the voltage may be set too high or the conductivity of the bath liquid is abnormal, and it should be adjusted in a timely manner.



Finally, it is recommended to carry out regular comparative tests between voltage and coating performance. By detecting indicators such as coating thickness, adhesion, hardness, and corrosion resistance, the voltage setting scheme can be continuously optimized.



Four, Conclusion

　　In summary, voltage is an important parameter that cannot be ignored in the electrocoating process. Its setting needs to be considered comprehensively from multiple aspects such as the characteristics of the paint, the condition of the workpiece, the state of the bath liquid, and the production requirements. By scientifically and reasonably setting the voltage, not only can the quality and efficiency of the electrocoating process be improved, but also the service life of the equipment can be extended, and the goal of energy-saving and environmental protection production can be achieved. Therefore, strengthening the control and management of voltage is a necessary means to ensure the stability of the electrocoating process.
