How to control stresses in thin film materials
Category：answer Publishing time：2025-09-03 09:00:04 Browse： Times
In fields such as modern microelectronics, optoelectronics, sensors, and nanotechnology, the application of thin film materials is becoming increasingly widespread. However, due to factors such as the difference in thermal expansion coefficients between the substrate and the thin film material, lattice mismatch, and deposition conditions (such as temperature and rate), residual stresses often occur within the thin film during the deposition process. If these stresses cannot be effectively controlled, they may lead to cracking, peeling, bending, and even failure of the devices. Therefore, studying how to control stresses in thin film materials is of great significance for improving device performance and reliability.
One, Sources of Thin Film Stress
Film stress is mainly divided into two types: thermal stress and intrinsic stress. Thermal stress originates from the strain caused by the difference in thermal expansion coefficients between the film and the substrate during the cooling process; intrinsic stress is related to the microstructure of the film, such as grain size, defect density, deposition rate, and energy input. In addition, film thickness, deposition method (such as sputtering, evaporation, chemical vapor deposition, etc.) will also affect the size and direction of stress.
Two, Methods of Controlling Thin Film Stress
1. Optimization of Deposition Parameters
By adjusting the parameters in the deposition process, such as temperature, pressure, gas flow rate, sputtering power, etc., the growth mode and microstructure of the film can be effectively controlled, thereby controlling the stress. For example, increasing the deposition temperature usually helps grain growth, reduces defect density, and thus reduces intrinsic stress; however, too high temperature may exacerbate thermal stress.
2. Introduction of Buffer Layer or Intermediate Layer
Inserting a buffer material between the substrate and the functional film can alleviate the stress caused by lattice mismatch and thermal expansion differences. Common buffer materials include silicon oxide, silicon nitride, titanium, tungsten, and other metals or compounds. This method is widely used in semiconductor devices and coating technology.
3. Multi-layer Structural Design
Using the method of alternating deposition of multiple layers, the stress interaction cancellation effect between different layers can be utilized to achieve overall stress balance. For example, depositing a compressive stress film on a high tensile stress film can significantly reduce overall deformation.
4. Annealing Treatment
Applying appropriate heat treatment (annealing) to the film after deposition can promote grain rearrangement and release defects, thereby effectively reducing the residual stress within the film. The selection of annealing temperature needs to take into account the thermal stability of the material and the temperature resistance of the substrate.
5. Ion Beam Assisted Deposition
Introducing ion beam bombardment in the deposition process can enhance the ability of atomic migration, improve the density and crystal structure of the film, thereby regulating the stress state. This method is particularly suitable for the preparation of high-density, low-stress films.
Three, Application and Prospects
With the development of advanced manufacturing technology, the requirements for the performance of thin film materials are becoming higher and higher. Controlling thin film stress is not only a key step to improve the reliability of devices but also the foundation for realizing new functional structures such as flexible electronic devices and microelectromechanical systems (MEMS). The future research direction will pay more attention to multi-scale stress regulation, intelligent deposition parameter optimization, and the development of new materials.
In summary, the control of thin film stress is a complex but crucial technology. Through scientific material design and process control, high-performance and high-stability thin film devices can be realized, providing solid support for technological progress.
