Anodizing is a widely used technique for surface treatment of aluminum and its alloys, which forms a dense oxide film on the metal surface by applying an electric current in a specific electrolyte solution, thereby improving the material's corrosion resistance, wear resistance, and decorative properties. The selection of the electrolyte is one of the key factors determining the performance and quality of the oxide film in the anodizing process. Therefore, how to scientifically and reasonably select the electrolyte is an issue that must be paid attention to in the anodizing process.

　　One, The relationship between electrolyte type and oxide film performance



Common anodizing electrolytes mainly include sulfuric acid, oxalic acid, chromic acid, phosphoric acid, and mixed acids. The oxide films formed by different types of electrolytes have different structures and properties:



1. Sulfuric acid electrolyte: The most commonly used, with the advantages of low cost, simple operation, and good transparency of the film, suitable for decorative and general functional anodizing.



2. Oxalic acid electrolyte: The formed oxide film has high hardness and strong corrosion resistance, but it has high energy consumption and a yellowish color, mainly used in occasions with high wear resistance requirements.



3. Chromic acid electrolyte: Suitable for thin layer oxidation, the film is dense and has good corrosion resistance, but it has a large environmental pollution and is subject to restrictions on use.



4. Phosphoric acid electrolyte: The film is porous and suitable as a base for coatings, commonly used in pretreatment before painting.



Two, Considerations for Selecting Electrolytes



1. Workpiece material: Different compositions of aluminum alloys have different adaptability to electrolytes. For example, aluminum alloys with high silicon content are prone to produce white spot defects in sulfuric acid electrolytes, and mixed acid or other types of electrolytes should be considered.



2. Film performance requirements: If a good decorative film is required, it is advisable to use the sulfuric acid system; if emphasis is placed on wear resistance and hardness, consideration can be given to oxalic acid or hard anodizing processes.



3. Environmental protection and safety: With increasingly strict environmental protection regulations, traditional chromium-containing processes are gradually being replaced by green alternative solutions, such as chromium-free electrolytes or organic acid systems.



4. Process conditions and equipment requirements: Different electrolytes have different requirements for current density, temperature control, cooling systems, etc., which need to be selected in combination with the existing equipment capabilities.



Three, Matching of Electrolyte Concentration and Process Parameters



In addition to the selection of types, the concentration, temperature, current density, and power-on time of the electrolyte and other process parameters also need to be comprehensively considered. For example, the concentration of sulfuric acid is generally controlled between 15% and 20%, the temperature is controlled between 18~22°C, and the current density is between 1~2 A/dm². Parameters that are too high or too low will affect the film quality, even causing burning or uneven film.



Four, Development Trends and New Electrolytes

　　With the development of science and technology, new environmentally friendly electrolytes are constantly emerging, such as boric acid-sulfuric acid mixed systems and ionic liquid electrolytes, which not only reduce the impact on the environment but also improve the performance of the oxide film. In addition, micro-arc oxidation technology is also gradually rising, and the electrolyte used is usually silicate, phosphate, and other alkaline systems, which can form ceramic layers under high voltage and has higher corrosion resistance and insulation properties.



Conclusion



In summary, selecting the appropriate electrolyte in the anodizing process is a key link to ensure product quality and process stability. Enterprises should scientifically and reasonably select and adjust the electrolyte formula according to specific materials, performance requirements, environmental protection standards, and equipment conditions to achieve the best oxidation effect. At the same time, paying attention to the research and development trends of new electrolytes helps to promote the development of anodizing technology towards green and efficient directions.
